Service Manual 19
Raption
3.B — CIRCUIT BREAKER Raption 50 HV, Raption 50 EVO AND Raption
100
2
1
1- Differential circuit breaker 16A
30mA Class A (Q3.2)
2- Switch disconnector 3 poles
+ neutral 250A (Q3.1). Main
circuit breaker
3- Terminal block
Note: in order to find more details about the cable installation, please, refer to the
Installation Manual.
