SNMP
Notification Recipients
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 463
24
- Link Local—The IPv6 address uniquely identifies hosts on a single network link. A
link local address has a prefix of FE80, is not routable, and can be used for
communication on the local network only. Only one link local address is supported.
If a link local address exists on the interface, this entry replaces the address in the
configuration.
- Global—The IPv6 address is a global Unicast IPV6 type that is visible and
reachable from other networks.
• Link Local Interface—If the IPv6 address type is Link Local, select whether it is
received through a VLAN or ISATAP.
• Recipient IP Address/Name—Enter the IP address or server name of where the traps
are sent.
• UDP Port—Enter the UDP port used for notifications on the recipient device.
• Notification Type—Select whether to send Traps or Informs. If both are required, two
recipients must be created.
• Timeout—Enter the number of seconds the device waits before re-sending informs.
• Retries—Enter the number of times that the device resends an inform request.
• Community String—Select from the pull-down the community string of the trap
manager. Community String names are generated from those listed in the Communities
page.
• Notification Version—Select the trap SNMP version.
Either SNMPv1 or SNMPv2 may be used as the version of traps, with only a single
version enabled at a time.
• Notification Filter—Select to enable filtering the type of SNMP notifications sent to
the management station. The filters are created in the Notification Filter page.
• Filter Name—Select the SNMP filter that defines the information contained in traps
(defined in the Notification Filterpage).
STEP 5 Click Apply. The SNMP Notification Recipient settings are written to the Running
Configuration file.
