SNMP
Notification Recipients
464 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
24
SNMPv3 Notification Recipients
To define a recipient in SNMPv3:
STEP 1 Click SNMP > Notification Recipients SNMPv3.
This page displays recipients for SNMPv3.
• Informs IPv4 Source Interface—Select the source interface whose IPv4 address will
be used as the source IPv4 address in inform messages for communication with IPv4
SNMP servers.
• Traps IPv4 Source Interface—Select the source interface whose IPv6 address will be
used as the source IPv6 address in trap messages for communication with IPv6 SNMP
servers.
• Informs IPv6 Source Interface—Select the source interface whose IPv4 address will
be used as the source IPv4 address in inform messages for communication with IPv4
SNMP servers.
• Traps IPv6 Source Interface—Select the source interface whose IPv6 address will be
used as the source IPv6 address in trap messages for communication with IPv6 SNMP
servers.
STEP 2 Click Add.
STEP 3 Enter the parameters.
• Server Definition—Select whether to specify the remote log server by IP address or
name.
• IP Version—Select either IPv4 or IPv6.
• IPv6 Address Type—Select the IPv6 address type (if IPv6 is used). The options are:
- Link Local—The IPv6 address uniquely identifies hosts on a single network link. A
link local address has a prefix of FE80, is not routable, and can be used for
communication on the local network only. Only one link local address is supported.
If a link local address exists on the interface, this entry replaces the address in the
configuration.
- Global—The IPv6 address is a global Unicast IPV6 type that is visible and
reachable from other networks.
• Link Local Interface—Select the link local interface (if IPv6 Address Type Link Local
is selected) from the pull-down list.
