Cisco 350 Series Administration Guide

Smart Network Application (SNA)
DAC Workflow
514 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
25
The report displays the following fields:
Field Value Comments
Device The device identifiers (Host name, IP
address)
Action Possible actions for DAC server:
• Enable RADIUS server
• Disable RADIUS server
• Update client list
• Create RADIUS server group
• Delete RADIUS server group
Possible actions for DAC client:
• Add RADIUS server connection
• Update RADIUS server connection
• Remove RADIUS server connection
• Update 802.1x settings
• Update interface authentication
settings
• Update interface host and session
settings
It is possible (and likely) for
multiple actions to appear for
each device.
Each action can have its own
status.
Warnings Possible warnings for DAC server include:
• Selected IP interface is dynamic.
Possible warnings for DAC clients include:
• Device is already a client of a
different RADIUS server.
• No ports are selected.
Warnings also contain links
to the sections of the DAC
where they can be addressed.
Changes can be applied when
warnings are present.
Status • Pending
• Success
• Failure
When the status is a failure,
the error message is shown
for the action.

Cisco 350 Series Specifications

General

Model	Cisco 350 Series
Category	Switch
Ports	8, 24, 48
PoE	Available on some models
Layer	Layer 2
Switching Capacity	Up to 104 Gbps
VLAN Support	Yes (up to 256 VLANs)
QoS	Yes
Management	Web, CLI, SNMP
Security Features	ACLs, 802.1X, Port Security
Jumbo Frame Support	Yes
Power Supply	Internal
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	10% to 90% non-condensing
Port Type	Gigabit Ethernet, Fast Ethernet (depending on model)
