3-44
Cisco 7600 Series Router SIP, SSC, and SPA Hardware Installation Guide
OL-5052-08
Chapter 3 Overview: Cisco 7600 Series Router Shared Port Adapters
1-Port 10-Gigabit Ethernet SPA Overview
XFP Optical Transmit and Receive Specifications
Table 3-24 provides XFP optical transmit and receive specifications.
XFP Module Ordering Information
Table 3- 25 provides ordering information.
Table 3-23 XFP Port Cabling Specifications
XFP Wavelength Cable Type
Core Size
(micron) Cable Distance
1
1. Minimum cabling distance for optical XFP module is 2 meters, according to the IEEE 802.3ae standard.
Cisco Multirate 10GBASE-LR
and OC-192/STM-64 SR-1 XFP
Module for SMF
1310 nm SMF G652 10 km (10 Gigabit Ethernet)
Cisco Multirate 10GBASE-ER
and OC-192/STM-64 IR-2 XFP
Module for SMF
2
2. Requires 5 dB 1550 nm fixed loss attenuator for < 20 km. Attenuator is available as a spare. The part number is 15216-ATT-LC-5=. You must
use a 5 to 10dB of attenuation when connecting a fiber loopback to the XFP optical port. Connection of a direct fiber loopback to the XFP can
permanently damage the port's optics.
1550 nm SMF G652 40 km
3
(10 Gigabit Ethernet)
3. Links longer than 30 km are considered engineered links.
Cisco Multirate 10GBASE-ZR
and OC-192/STM-64 IR-2 XFP
Module for SMF
1550 nm SMF G652 80 km
3
(10 Gigabit Ethernet)
Table 3-24 XFP Optical Transmit and Receive Specifications
XFP Type Transmit Power (dBm) Receive Power (dBm)
Receive
Wavelength (nm)
Maximum Minimum Maximum Minimum
Cisco Multirate
10GBASE-LR and
OC-192/STM-64 SR-1 XFP
Module for SMF
10GBASE-LR
1310-nm SMF
+0.5 -8.2 +0.5 -14.4 1260 to 1565
Cisco Multirate
10GBASE-ER and
OC-192/STM-64 IR-2 XFP
Module for SMF
10GBASE-ER
1550-nm SMF
+4.0 -4.7 -1.0 -15.8 1260 to 1565
Cisco Multirate
10GBASE-ZR and
OC-192/STM-64 IR-2 XFP
Module for SMF
10GBASE-ZR
1550-nm SMF
+4.0 0 -7 -24 1260 to 1565
