Cisco 7600 Series Router SIP, SSC, and SPA Hardware Installation Guide
OL-5052-08
Chapter 3 Overview: Cisco 7600 Series Router Shared Port Adapters
24-Port Channelized T1/E1 ATM CEoP SPA Overview
Table 3-41 24-Port Channelized T1/E1 ATM CEoP SPA Cable Connector Pinouts
Subscriber Connector Pins
Line Signal SPA TX Cable Lead RX Cable Lead
Line 1 TX Tip
TX Ring
2
52
1
26
Not connected
RX Tip
RX Ring
26
76
Not connected 1
26
Line 2 TX Tip
TX Ring
3
53
2
27
Not connected
RX Tip
RX Ring
27
77
Not connected 2
27
Line 3 TX Tip
TX Ring
4
54
3
28
Not connected
RX Tip
RX Ring
28
78
Not connected 3
28
Line 4 TX Tip
TX Ring
5
55
4
29
Not connected
RX Tip
RX Ring
29
79
Not connected 4
29
Line 5 TX Tip
TX Ring
6
56
5
30
Not connected
RX Tip
RX Ring
30
80
Not connected 5
30
Line 6 TX Tip
TX Ring
7
57
6
31
Not connected
RX Tip
RX Ring
31
81
Not connected 6
31
Line 7 TX Tip
TX Ring
8
58
7
32
Not connected
RX Tip
RX Ring
32
82
Not connected 7
32
Line 8 TX Tip
TX Ring
9
59
8
33
Not connected
RX Tip
RX Ring
33
83
Not connected 8
33
Line 9 TX Tip
TX Ring
10
60
9
34
Not connected
RX Tip
RX Ring
34
84
Not connected 9
34
Line 10 TX Tip
TX Ring
11
61
10
35
Not connected
RX Tip
RX Ring
35
85
Not connected 10
35
