Figure 8: Phone to Wall Bracket Attachment
Step 5 Press the phone firmly into the wall bracket and slide the phone down. The tabs in the bracket click into
position.
Step 6 Proceed to Adjust the Handset Rest, on page 115.
Remove the Phone from the Non-Lockable Wall Mount for 7811
The wall mounting plate contains two tabs to lock the plate into the phone bracket. The following figure shows
the location and shape of the tabs.
Cisco IP Phone 7800 Series Multiplatform Phones Administration Guide
97
Hardware and Accessory Installation
Remove the Phone from the Non-Lockable Wall Mount for 7811
