Chapter 3 Connecting the Router
Connecting a Voice ISDN BRI Line
Figure 3-32 shows a voice BRI line connection.
Figure 3-32 Connecting a Voice BRI Line
Step 2 Connect the other end of the cable to the RJ-45 telephone outlet or other device.
1 Voice BRI port 3 Telephone outlet
2 RJ-45 cable
