Cisco 860 Series User Manual

1
Cisco Integrated Services Router Hardware Installation Guide
CONTENTS
Preface vii
Objective vii
Audience vii
Organization viii
Conventions viii
Related Documentation xvi
Searching Cisco Documents xvi
Obtaining Documentation and Submitting a Service Request xvi
Product Overview 1-1
Cisco 810 Series 1-1
Cisco 812 Series 1-1
General Description 1-1
Hardware Features 1-4
SKU Information 1-9
Cisco 819 Series 1-10
General Description 1-10
SKU Information 1-14
Hardware Features 1-19
Cisco 860, 880, 890 Series 1-33
General Description 1-34
Cisco 860 Series ISRs 1-34
Cisco 860VAE Series ISRs 1-36
Interfaces 1-36
IOS Images 1-36
Cisco 860VAE-W-A-K9, Cisco 860VAE-W-E-K9, and
Cisco 860VAE-POE-W-A-K9 ISRs
1-38
Model-Specific Features 1-38
Common Features 1-39
Cisco 880 Series ISRs 1-42
Cisco 880 Series Data Routers 1-43
Cisco 880 Series Voice and Data Routers 1-46
Cisco 880 Series with Embedded WLAN Antennas 1-52
C881G-B/S/V-K9 ISRs 1-54
C881GW-S/V-A-K9 ISRs 1-54

Cisco 860 Series Specifications

General

VPN Support	Yes
Firewall	Yes
QoS	Yes
Data Link Protocol	Ethernet, Fast Ethernet
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS
Operating System	Cisco IOS
Device Type	Router
WAN Interfaces	1 x 10/100Base-TX - RJ-45
LAN Interfaces	4 x 10/100Base-TX - RJ-45
Connectivity Technology	Wired
Network / Transport Protocol	IPSec, TCP/IP
Features	DHCP support, NAT support, VLAN support, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u
