1-33
Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 810 Series
Serial Port
The Cisco standard High Speed Smart Serial 12-in-1 connector allows the highest flexibility of
connections to various DTE/DCE devices. The 12-in-1 serial interface pins connect to the FPGA. The
FPGA configures the pin directions based on the cable type used. Figure 1-10 shows the magnified view
of the 12-in-1 serial port. For more information, see About Serial Connections.
4G-CAB-LMR240-50 50 ft (15 m) 4.1 dB at 700 MHz
7.4 dB at 2.6 GHz
700 to 1000 MHz
1700 to 2600 MHz
Black Yes
4G-CAB-LMR240-75 75 ft (23 m) 6.1 dB at 700 MHz
11.0 dB at 2.6 GHz
700 to 1000 MHz
1700 to 2600 MHz
Black Yes
4G-CAB-LMR240-25N 25 ft (7.6 m) 2.1 dB at 700 MHz
4.0 dB at 2600 MHz
700 to 1000 MHz
1700 to 2600 MHz
Black No
4G-CAB-ULL-20 20 ft (6 m) 1.8 dB 700 to 2600 MHz Black Yes
4G-CAB-ULL-50 50 ft (15 m) 4.2 dB 700 to 2600 MHz Black Yes
CAB-L400-20-TNC-N 20 ft (6 m) 1.75 dB 700 to 2600 MHz Black No
CAB-L400-50-TNC-N 50 ft (15 m) 4.0 dB 700 to 2600 MHz Black No
CAB-L400-20-N-N 20 ft (6 m) 2.75 dB 700 to 2600 MHz Black No
1. Cable can be routed within building plenum spaces.
Table 1-18 Cisco Extension Cables for Use with 4G LTE Antennas (continued)
Cisco Product Number Cable Length
Maximum Insertion
Loss Frequency (MHz) Color Plenum Rated?
1
