Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 860, 880, 890 Series
Table 1-25 describes the LED indicators.
Cisco 880 Series ISRs
The Cisco 880 series ISRs have data and voice capabilities. They have the following features:
Table 1-25 Front Panel LED Indicators
LED LED Color LED Activity Description
Left Side
DSL ACT Green Flashing DSL WAN activity. Faster flashing indicates heavier
traffic.
Off — Device is powered off.
or
No DSL WAN activity.
DSL LINK Green Solid DSL WAN mode is selected and DSL training is complete.
Flashing DSL WAN mode is selected but DSL LinkUp state is
incomplete, such as in-training (slow initially, fast when
almost connected).
Off — Device is powered off.
or
GE WAN mode is selected.
GE ACT Green Flashing GE WAN activity (traffic in either direction). Faster
flashing indicates heavier traffic.
Off — Device is powered off.
or
No GE WAN activity.
or
No link.
GE MODE Green Solid GE WAN mode is selected.
Off — Device is powered off.
or
DSL WAN mode is selected.
Right Side
WLAN Green Solid WLAN enabled.
Flashing Indicates WLAN activity (traffic in either direction).
Off — Device is powered off.
or
WLAN is disabled.
Power Green Solid On—The device is powered on.
Off — Device is powered off.

Cisco 860 Series Specifications

General

VPN Support	Yes
Firewall	Yes
QoS	Yes
Data Link Protocol	Ethernet, Fast Ethernet
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS
Operating System	Cisco IOS
Device Type	Router
WAN Interfaces	1 x 10/100Base-TX - RJ-45
LAN Interfaces	4 x 10/100Base-TX - RJ-45
Connectivity Technology	Wired
Network / Transport Protocol	IPSec, TCP/IP
Features	DHCP support, NAT support, VLAN support, IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u
