Cisco ASR 9000 Series Service Configuration Guide

Configuring Modular QoS Congestion Management on Cisco ASR 9000 Series Routers
How to Configure QoS Congestion Management on Cisco ASR 9000 Series Routers
QC-54
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
Configuring Bandwidth Remaining
SUMMARY STEPS
1. configure
2. policy-map policy-name
3. class class-name
4. bandwidth remaining {percent percentage-value | ratio ratio-value}
5. exit
6. class class-name
7. bandwidth remaining {percent percentage-value | ratio ratio-value}
8. exit
9. class class-name
10. bandwidth remaining {percent percentage-value | ratio ratio-value}
11. exit
12. exit
13. interface type interface-path-id
Step 15
end
or
commit
Example:
RP/0/RSP0/CPU0:router(config-if)# end
or
RP/0/RSP0/CPU0:router(config-if)# commit
Saves configuration changes.
• When you issue the end command, the system prompts
you to commit changes:
Uncommitted changes found, commit them before
exiting(yes/no/cancel)?
[cancel]:
– Entering yes saves configuration changes to the
running configuration file, exits the configuration
session, and returns the router to EXEC mode.
– Entering no exits the configuration session and
returns the router to EXEC mode without
committing the configuration changes.
– Entering cancel leaves the router in the current
configuration session without exiting or
committing the configuration changes.
• Use the commit command to save the configuration
changes to the running configuration file and remain
within the configuration session.
Step 16
show policy-map interface type
interface-path-id [input | output]
Example:
RP/0/RSP0/CPU0:router# show policy-map
interface gigabitethernet 0/2/0/0
(Optional) Displays policy configuration information for all
classes configured for all service policies on the specified
interface.
Command or Action Purpose
