Cisco ASR 9000 Series Service Configuration Guide

Configuring Modular QoS Congestion Management on Cisco ASR 9000 Series Routers
How to Configure QoS Congestion Management on Cisco ASR 9000 Series Routers
QC-55
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
14. service-policy {input | output} policy-map
15. end
or
commit
16. show policy-map interface type instance [input | output]
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
policy-map policy-name
Example:
RP/0/RSP0/CPU0:router(config)# policy-map
policy1
Enters policy map configuration mode.
• Creates or modifies a policy map that can be attached to
one or more interfaces to specify a service policy.
Step 3
class class-name
Example:
RP/0/RSP0/CPU0:router(config-pmap)# class
class1
Specifies the name of the class whose policy you want to
create or change.
Step 4
bandwidth remaining percent percentage-value
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# bandwidth
remaining percent 40
Specifies how to allocate leftover bandwidth for class
class1.
Step 5
exit
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# exit
Returns the router to policy map configuration mode.
Step 6
class class-name
Example:
RP/0/RSP0/CPU0:router(config-pmap)# class
class2
Specifies the name of the class whose policy you want to
create or change.
Step 7
bandwidth remaining percent percentage-value
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# bandwidth
remaining percent 40
Specifies how to allocate leftover bandwidth for class
class2.
Step 8
exit
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# exit
Returns the router to policy map configuration mode.
