Cisco ASR 9000 Series Service Configuration Guide

Configuring Modular QoS Congestion Management on Cisco ASR 9000 Series Routers
How to Configure QoS Congestion Management on Cisco ASR 9000 Series Routers
QC-64
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
Step 5
conform-action action
Example:
RP/0/RSP0/CPU0:router(config-pmap-c-police)#
conform-action set mpls experimental topmost 3
Configures the action to take on packets that conform to the
rate limit. The action argument is specified by one of the
following keywords:
• drop—Drops the packet.
• set—Has the following keywords and arguments:
– cos value—Sets the class of service value. Range is
0 to 7.
– discard-class value—Sets the discard class value.
Range is 0 to 7.
– dscp value—Sets the differentiated services code
point (DSCP) value and sends the packet.
– mpls experimental {topmost | imposition}
value—Sets the experimental (EXP) value of the
Multiprotocol Label Switching (MPLS) packet
topmost label or imposed label. Range is 0 to 7.
– precedence precedence—Sets the IP precedence
and sends the packet.
– qos-group—Sets the QoS group value. Range is 0
to 63.
• transmit—Transmits the packets.
Step 6
exceed-action action
Example:
RP/0/RSP0/CPU0:router(config-pmap-c-police)#
exceed-action set mpls experimental topmost 4
Configures the action to take on packets that exceed the rate
limit. The action argument is specified by one of the
keywords specified in
Step 5.
Step 7
exit
Example:
RP/0/RSP0/CPU0:router(config-pmap-c-police)#
exit
Returns the router to policy map class configuration mode.
Step 8
exit
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# exit
Returns the router to policy map configuration mode.
Step 9
exit
Example:
RP/0/RSP0/CPU0:router(config-pmap)# exit
Returns the router to global configuration mode.
Step 10
interface type interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# interface
gigabitethernet 0/5/0/0
Enters configuration mode and configures an interface.
Command or Action Purpose

Cisco ASR 9000 Series Specifications

General

Series	ASR 9000
Category	Network Router
Modular Design	Yes
Redundancy	Yes (Hardware and Software)
Operating System	Cisco IOS XR
Interfaces/Ports	10G, 40G, 100G, 400G Ethernet
Expansion Slots	Varies by model
Routing Protocol	BGP, OSPF, IS-IS, EIGRP
Management	CLI, SNMP, NETCONF
Power Supply	Redundant
Port Density	Varies by model
Power Supply Options	AC, DC
Memory	Varies by model
Storage	Varies by model
Dimensions	Varies by model
Weight	Varies by model
