Cisco ASR 9000 Series Service Configuration Guide

Configuring Modular QoS Congestion Avoidance on Cisco ASR 9000 Series Routers
How to Configure Modular QoS Congestion Avoidance on Cisco ASR 9000 Series Routers
QC-78
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
Step 5
bandwidth { bandwidth [ units ] | percent value }
or
bandwidth remaining [percent value | ratio
ratio-value
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# bandwidth
percent 30
or
RP/0/RSP0/CPU0:router(config-pmap-c)# bandwidth
remaining percent 20
(Optional) Specifies the bandwidth allocated for a class
belonging to a policy map.
or
(Optional) Specifies how to allocate leftover bandwidth to
various classes.
Note One of these configurations is required for a
non-default class.
Step 6
shape average {percent percentage | value
[ units ]}
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# shape
average percent 50
(Optional) Shapes traffic to the specified bit rate or a
percentage of the available bandwidth.
Step 7
exit
Example:
RP/0/RSP0/CPU0:router(config-pmap-c)# exit
Returns the router to policy map configuration mode.
Step 8
exit
Example:
RP/0/RSP0/CPU0:router(config-pmap)# exit
Returns the router to global configuration mode.
Step 9
interface type interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# interface
TenGigE 0/2/0/0
Enters configuration mode and configures an interface.
Command or Action Purpose
