Cisco ASR 9000 Series Service Configuration Guide

Configuring Modular QoS Congestion Avoidance on Cisco ASR 9000 Series Routers
How to Configure Modular QoS Congestion Avoidance on Cisco ASR 9000 Series Routers
QC-80
Cisco ASR 9000 Series Aggregation Services Router Modular Quality of Service Configuration Guide
OL-23108-02
SUMMARY STEPS
1. configure
2. policy-map policy-name
3. class class-name
4. random-detect dscp dscp-value min-threshold [units] max-threshold [units]
5. bandwidth {bandwidth [units] | percent value}
or
bandwidth remaining [percent value | ratio ratio-value]
6. shape average {percent | value [units]}
7. queue-limit value [units]
8. exit
9. interface type interface-path-id
10. service-policy {input | output} policy-map
11. end
or
commit
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
policy-map policy-name
Example:
RP/0/RSP0/CPU0:router(config)# policy-map
policy1
Enters policy map configuration mode.
• Creates or modifies a policy map that can be attached to
one or more interfaces to specify a service policy.
Step 3
class class-name
Example:
RP/0/RSP0/CPU0:router(config-pmap)# class
class1
Enters policy map class configuration mode.
• Specifies the name of the class whose policy you want
to create or change.
