Cisco ASR 903 Installation Guide

Table 40: Management Ethernet Port Pinout
Signal
Name
Pin
TRP0+1
TRP0-2
TRP1+3
TRP1-4
TRP2+5
TRP2-6
TRP3+7
TRP3-8
USB Console Port Pinout
Two individual Type-A USB connector are used for USB console and USB mass storage. One single USB
2.0 Type-A receptacle is provided on the RSP front panel for providing console access to ROMMON, IOS-XE
and diagnostics. It operates as a USB peripheral only for connection to an external host PC. This requires the
use of a Type-A to Type-A connector instead of a standard USB cable.
The use of the USB console is mutually exclusive with the RS232 console/Aux port. While a USB cable is
inserted, access is automatically switched to this port.
Note
The other single USB 2.0 Type-A receptacle is provided on the RSP front panel for inserting external USB
mass storage devices such as standard USB flash drives. It is used to load images, store configurations, write
logs, etc. It supports operation up to 12Mbps.
The table below summarizes the USB console port pinout.
Table 41: Single USB Console Port
DescriptionDirectionSignal NamePin
+5VDC (500mA)—VccA1
Data -—D-A2
Data +—D+A3
Ground—GndA4
Cisco ASR 903 and ASR 903U Aggregation Services Router Hardware Installation Guide
175
Troubleshooting
USB Console Port Pinout
