Cisco CATALYST 2960 Installation

1-19
Catalyst 2960-S Switch Hardware Installation Guide
OL-19732-04
Chapter 1 Switch Installation
Installing the Power Cord Retainer (Optional)
Step 3 Slide the retainer through the first latch. See Figure 1-19.
Figure 1-19 Sliding the Retainer Through the Latch
Step 4
Slide the retainer through the other latches to lock it. See Figure 1-20.
Figure 1-20 Locking the Retainer
Step 5
(Optional) Use the small sleeve for thin power cords. Use the small sleeve to provide greater stability for
thin cords. Detach the sleeve, and slide it over the power cord. See Figure 1-21.
1 AC power cord 3 Latch
2 Smaller sleeve for thin power cords
RATING
100-240~
12-6A, 50-60Hz
1
2 3
333872
1 AC power cord 3 Latches
2 Sleeve for thin power cords
RATING
100-240~
12-6A, 50-60Hz
1
2 3
333873

Cisco CATALYST 2960 Specifications

General

Manageable	Yes
Stacking	No
Model	Catalyst 2960 Series Switches
Power over Ethernet (PoE)	Available on some models (IEEE 802.3af)
VLANs	255 active VLANs
Features	QoS
Operating Temperature	32 to 113°F (0 to 45°C)
Relative Humidity	10% to 85% non-condensing
Power Consumption	Varies by model (30W to 400W)
