DescriptionDirectionSignalPin
Request to Send (tied
directly to CTS)
OutputRTS1
Data Terminal Ready
(always On)
OutputDTR2
Transmit DataOutputTXD3
——GND4
——GND5
Receive DataInputRXD6
UnusedInputDSR7
Clear to Send (tied to
RTS)
InputCTS8
Cisco Catalyst CW9800H1 and CW9800H2 Wireless Controllers Hardware Installation Guide
90
Port Signals and Pinouts
Port Signals and Pinouts
