APPENDIX B
Port Signals and Pinouts
This appendix provides the port signals and pinout specifications.
• Management Ethernet Port Signals and Pinouts, on page 89
• Console Port Signals and Pinouts, on page 89
Management Ethernet Port Signals and Pinouts
The following table lists the Management Ethernet 10/100/1000 RJ-45 port pinouts.
DescriptionDirectionSignalPin
T/R data +I/OTX/RX AData +1
T/R data -I/OTX/RX AData -2
T/R Data +I/OTX/RX BData +3
T/R Data + (Unused for
10/100)
I/OTX/RX CData +4
T/R Data - (Unused for
10/100)
I/OTX/RX CData -5
T/R Data -I/OTX/RX BData -6
T/R Data + (Unused for
10/100)
I/OTX/RX DData +7
T/R Data - (Unused for
10/100)
I/OTX/RX DData -8
Console Port Signals and Pinouts
The following table lists the pinouts of the RJ-45 console port.
