Chapter 3 Installing the Content Delivery Engines
Installing the CDEs
Figure 3-23 Attaching the Rev. B Rails to the CDE
Step 4
Secure the inner rails with screws (optional).
Step 5 Press the locking tab and push the middle rail back into the outer rail.
1 CDE 2 Rail assemblies
3 Screws
1
2
209586
2
2
1
3
3
