Ring volume lets you set the volume of the incoming call signal. You will hear the
level as you adjust.
Key tones let you determine whether you should hear a sound every time you
press a key or not. Set to On to activate.
Flash screen on incoming calls. Set to On to activate.
Standby and screensaver
There is a standby function in the E20. When activated the standby function
makes the screen go black after a time interval (delay) specied by you. This
setting will override the screensaver feature.
You may add a screensaver of your choice to the E20. You will need a USB disk
containing the photos (illustrations) you want to use as screensaver. If the USB
stick contains multiple pictures, the contents will be shown as a gallery, one
picture at a time.
A few things to observe:
• To continuously display the screensaver, the standby function must be
disabled.
• Once you have plugged in the USB disk, the E20 will produce a dialog asking you
whether the pictures on the USB disk should be displayed by the USB picture
frame. The unit will read xcif data and even rotate images when necessary. The
prompt will let you specify the time interval between the last time you operated (or
used) the E20 and when the screensaver should start to appear.
• The USB disk must remain connected to the E20 to make this work.
• The following le formats are supported: *.jpg, *.png, *.gif.
Language
Choose between English, Norwegian, Swedish, German, French, Korean, Italian,
Dutch, Danish, Finnish, Portuguese, Japanese, Russian, Spanish, Spanish Latin,
Turkish, Chinese Traditional, Chinese Simplied.
Camera control
Camera control lets you move your own camera up and down, in addition to set the
exposure and whitebalance. Note that the camera will not move up and down physically,
but the image will.
In a call, a softbutton for camera control will appear (the button in the middle). Pressing
this will cause the unit to attempt to start moving the far end camera (Far End Camera
Controll—FECC). To move your own camera press the softbutton Near end camera
(the leftmost button). Your own camera can be moved in vertical direction only.
Exposure and Whitebalance can be set manually or you can leave it up to the
E20 to set it for you.
Bluetooth™
You may connect a Bluetooth™ headset to the E20. To do that, you have to turn
the Bluetooth support in the E20 to On and set your Bluetooth device in pairing
mode.
Call forward
Call forward lets you forward all calls to a dened receiver. Just key in the identity
and then activate the feature. When used with CUCM, the call forward information
will also be known by the CUCM server. Changing this on the server or in the E20 will
change the other setting accordingly. This implies that call forward will take place even
if the E20 is unpowered, whenever it is used with CUCM. When not used with CUCM,
the E20 must stay powered and connected for call forward to work.
Call settings
Auto answer can be set to O or On. When set to O you must respond to an
incoming call to accept it, either by lifting the handset or by pressing the
key. When
set to On, the call is automatically accepted.
Default bitrate in calls can be set to 1152, 768, 512, 384, 256 or 128 kbps.
Maximum upstream bitrate: 1152, 768, 512, 384, 256 or 128 kbps.
Maximum downstream bitrate 1152, 768, 512, 384, 256 or 128 kbps.
The reason for allowing dierent upstream and downstream bitrate is to meet the
need to specify dierent settings in asymmetric internet connections—typically when
operating the E20 from home.
Date and time
Date and time can be set to either Manual or Automatic.
If set to Automatic the menu allows you to update Time zone, Date format and
Time format only. When set to Manual you may change Day, Month, Year, Time
upon 12/24 hrs, Date format and Time format.
