Configuring H.323 and SIP
(When not set by a provisioning system)
To get online and ready to place and receive calls, your system
must be set up properly. Your system uses either the H.323
protocol or the SIP protocol for video calls.
NOTE: Contact your system administrator, or service provider,
for information about the network settings.
For networks administered through Cisco TMS (Cisco
TelePresence Management Suite), your Cisco TMS adminis-
trator will help you to get online.
You can find information about administering through Cisco UCM
in the Administering TC endpoints on CUCM guide.
The diagnostics on your system will indicate if there is a problem
with the H.323 or SIP registering.
NOTE: H.323. is not available for the SX10.
H.323
If in doubt for any of the parameters below, contact your system
administrator or your service provider.
1.
Go to the Configuration tab, and select System Configuration.
2. Open the H323 settings from the left sidebar.
3.
Under Profile1 heading and the H323Alias subheading, enter
the E164 and the ID number in their respective input fields.
4. Go to the Gatekeeper subheading.
If you want the system to obtain the H.323 gatekeeper
address automatically, select Auto in the Discovery drop
down list; if you want to enter the address manually, select
Manual.
If set to Manual, enter the gatekeeper Address in the corre-
sponding input field.
5.
If the H.323 gatekeeper requires authentication, and you
want your system to authenticate itself to the gatekeeper, go
to the Authentication subheading and select On in the Mode
drop down list. Then enter the LoginName and Password in
the corresponding input fields.
Otherwise, select Off in the Mode drop down list.
6.
Click the Home tab to see the System Information and verify
the H.323 settings.
If you have successfully registered to a Gatekeeper, the
Status is shown as Registered in the H323 section.
If you wish to change the other H.323 settings, check the admin-
istrator guide for your product.
SIP
If in doubt for any of the parameters below, contact your system
administrator or your service provider.
1.
Go to the Configuration tab, and select System Configuration.
2. Open the SIP page from the left sidebar.
3.
Under the Profile 1 heading, enter the SIP URI in the URI
input field, and optionally a display name in the DisplayName
input field.
Select the preferred transport protocol from the
DefaultTranspor t drop down list. If you select Auto, the
system first tries to connect using Tls, then TCP, and finally
U D P.
4.
Select a proxy type in the Type drop down list. The default
type is Standard.
5. Go to the Proxy 1 subheading.
If you want the system to obtain the SIP proxy address
automatically, select Auto in the Discovery drop down list;
if you want to enter the address manually, select Manual.
If you select Manual, enter the proxy Address in the corre-
sponding input field.
6.
If the SIP proxy requires authentication, you must enter a
login name and password to authenticate your system. Go
to the Authentication 1 subheading and enter the LoginName
and Password in the corresponding input fields.
7.
Click the Home tab to see the System Information and verify
the SIP settings.
If you have successfully registered to a SIP server, the
Status is shown as Registered in the SIP section.
If you wish to change the other SIP settings, check the admin-
istrator guide for your product.
If you are changing a value setting,
you have to always click save to confirm the change.
Back to task overview
Cisco TelePresence Video Systems
D14639.15 Video Systems Getting Started Guide TC7.2, OCTOBER 2014.
Copyright © 2010–2014 Cisco Systems, Inc. All rights reserved.
26
