5-20

Cisco IE 3000 Switch Software Configuration Guide

OL-13018-03

Chapter 5 Configuring Cisco EnergyWise

Additional Information

Note To prevent a disjointed domain, you can also configure a helper address on Router A and specify that the

router use UDP to forward broadcast packets with the

ip helper-address address interface configuration command.

ip forward-protocol udp [port] global configuration command.
