Cisco IE-3000-8TC User Manual

26-3
Cisco IE 3000 Switch Software Configuration Guide
OL-13018-03
Chapter 26 Configuring Port-Based Traffic Control
Configuring Storm Control
You use the storm-control interface configuration commands to set the threshold value for each traffic
type.
Default Storm Control Configuration
By default, unicast, broadcast, and multicast storm control are disabled on the switch interfaces; that is,
the suppression level is 100 percent.
Configuring Storm Control and Threshold Levels
You configure storm control on a port and enter the threshold level that you want to be used for a
particular type of traffic.
However, because of hardware limitations and the way in which packets of different sizes are counted,
threshold percentages are approximations. Depending on the sizes of the packets making up the
incoming traffic, the actual enforced threshold might differ from the configured level by several
percentage points.
Note Storm control is supported on physical interfaces. You can also configure storm control on an
EtherChannel. When storm control is configured on an EtherChannel, the storm control settings
propagate to the EtherChannel physical interfaces.
Beginning in privileged EXEC mode, follow these steps to storm control and threshold levels:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the interface to be configured, and enter interface
configuration mode.

Cisco IE-3000-8TC Specifications

General

Switching Capacity	16 Gbps
MAC Address Table Size	8000
Uplink Ports	2 x 10/100/1000Base-T or SFP (Small Form-Factor Pluggable)
Operating Temperature	-40°C to 70°C
Mounting	DIN rail
Ports	8 x Ethernet 10/100Base-TX ports
Jumbo Frame Support	Yes
