37-9
Cisco IE 3000 Switch Software Configuration Guide
OL-13018-03
Chapter 37 Configuring IPv6 Host Functions
Configuring IPv6
To return to the default configuration, use the no ipv6 icmp error-interval global configuration
command.
This example shows how to configure an IPv6 ICMP error message interval of 50 milliseconds and a
bucket size of 20 tokens.
Switch(config)#ipv6 icmp error-interval 50 20
Configuring Static Routes for IPv6
Beginning in privileged EXEC mode, follow these steps to configure an IPv6 static route:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ipv6 route ipv6-prefix/prefix length
{ipv6-address | interface-id [ipv6-address]}
[administrative distance]
Configure a static IPv6 route.
ipv6-prefix—The IPv6 network that is the destination of the
static route. It can also be a hostname when static host routes are
configured.
/prefix length—The length of the IPv6 prefix. A decimal value
that shows how many of the high-order contiguous bits of the
address comprise the prefix (the network portion of the address).
A slash mark must precede the decimal value.
ipv6-address—The IPv6 address of the next hop that can be used
to reach the specified network. The IPv6 address of the next hop
need not be directly connected; recursion is done to find the
IPv6 address of the directly connected next hop. The address
must be specified in hexadecimal using 16-bit values between
colons.
interface-id—Specify direct static routes from point-to-point
and broadcast interfaces. With point-to-point interfaces, there is
no need to specify the IPv6 address of the next hop. With
broadcast interfaces, you should always specify the IPv6
address of the next hop, or ensure that the specified prefix is
assigned to the link, specifying a link-local address as the next
hop. You can optionally specify the IPv6 address of the next hop
to which packets are sent.
Note You must specify an interface-id when using a link-local
address as the next hop (the link-local next hop must also be
an adjacent router).
administrative distance—(Optional) An administrative distance.
The range is 1 to 254; the default value is 1, which gives static
routes precedence over any other type of route except connected
routes. To configure a floating static route, use an administrative
distance greater than that of the dynamic routing protocol.
Step 3
end Return to privileged EXEC mode.
