Cisco IE 3000 Series User Manual

1-13
Cisco IE 3000 Switch Hardware Installation Guide
OL-13017-01
Chapter 1 Overview
Power Converter (Optional)
Figure 1-11 Cisco IE 3000 Switch Rear Panel
Power Converter (Optional)
The switch can be used with an optional AC/DC power converter. The power converter
(PWR-IE3000-AC) can supply 24-VDC power to one switch and up to two modules. The power
converter is mounted on the side of a switch and provides power to the switch through a preassembled
power cable.
Note The power converter (PWR-IE3000-AC=) is sold separately.
You can get a replacement power cable (PWR-IE3000-CLP=) by calling Cisco Technical Support.
For installation and connection procedures for the power converter, see the “Connecting the Switch to
the Power Converter” section on page 2-44.
1 DIN rail latch 2 Foot in recessed position
1
2
201697

Cisco IE 3000 Series Specifications

General

Brand	Cisco
Model	IE 3000 Series
Category	Switch
Language	English
