Cisco IE 3000 Series User Manual

2-10
Cisco IE 3000 Switch Hardware Installation Guide
OL-13017-01
Chapter 2 Switch Installation
Installing or Removing the Compact Flash Memory Card
Figure 2-6 Pushing the Module Latches In
Step 6 (Optional) if the first module attached was an Cisco IEM-3000-8TM, you can connect another
Cisco IEM-3000-8TM or Cisco IEM-3000-8FM expansion module. Follow Step 1 to Step 5 to connect
the module.
Installing or Removing the Compact Flash Memory Card
The switches store Cisco IOS software images and switch configurations on a removable flash memory
card. You can replace the switch without reconfiguring it. The switch ships with the compact flash
memory card installed. Verify that the card is in place on the bottom of the switch.
201826

Cisco IE 3000 Series Specifications

General

Series	IE 3000
Form Factor	Compact, ruggedized
Power Supply	24 VDC
Mounting	DIN rail
Management	Web-based, CLI, SNMP
Network Protocols	IEEE 802.3
MAC Address Table Size	8000
Input Voltage	24 VDC
Power Consumption	Varies by model and configuration
Dimensions	Varies by model
Weight	Varies by model
MTBF	Varies by model
PoE	Available on select models (PoE and PoE+)
Category	Industrial Ethernet Switch
