Chapter 2 Switch Installation
Adding Modules to the Switch
Table 2-1 lists the port combinations using switch and expansion modules.
Figure 2-1 shows example combinations of the Cisco IE-3000-4TC switch and expansion modules. Even
though the example configurations in Figure 2-1 show a Cisco IE-3000-4TC switch, the same
combinations of expansion modules can be used with a Cisco IE-3000-8TC switch.
Ta b l e 2-1 Switch and Expansion Module Examples
Port Type Switch and Expansion Modules Combination
10/100FE 100FX Cisco IE-3000-4TC
4 1 Cisco IE-3000-4TC
8 1 Cisco IE-3000-8TC
4 8 1 Cisco IE-3000-4TC and 1 Cisco IEM-3000-8FM
12 1 Cisco IE-3000-4TC and 1 Cisco IEM-3000-8TM
8 8 1 Cisco IE-3000-8TC and 1 Cisco IEM-3000-8FM
16 1 Cisco IE-3000-8TC and 1 Cisco IEM-3000-8TM
12 8 1 Cisco IE-3000-4TC and 1 Cisco IEM-3000-8TM and 1 Cisco IEM-3000-8FM
20 1 Cisco IE-3000-4TC and 2 Cisco IEM-3000-8TM
16 8 1 Cisco IE-3000-8TC and 1 Cisco IEM-3000-8TM and 1 Cisco IEM-3000-8FM
24 1 Cisco IE-3000-8TC and 2 Cisco IEM-3000-8TM

Cisco IE 3000 Series Specifications

General

Series	IE 3000
Form Factor	Compact, ruggedized
Power Supply	24 VDC
Mounting	DIN rail
Management	Web-based, CLI, SNMP
Network Protocols	IEEE 802.3
MAC Address Table Size	8000
Input Voltage	24 VDC
Power Consumption	Varies by model and configuration
Dimensions	Varies by model
Weight	Varies by model
MTBF	Varies by model
PoE	Available on select models (PoE and PoE+)
Category	Industrial Ethernet Switch
