Table 12: Console Port Adapter Pinouts (RJ-45-to-DB-9)
Console DeviceRJ-45-to- DB-9 Terminal AdapterSwitch Console Port (DTE)
SignalDB-9 PinSignal
CTS8RTS
DSR6DTR
RxD2TxD
GND5GND
TxD3RxD
DTR4DSR
RTS7CTS
The RJ-45-to-DB-25 female DTE adapter is not supplied with the switch. You can order this adapter from
Cisco (part number ACS-DSBUASYN=).
Note
Table 13: Console Port Adapter Pinouts (RJ-45-to-DB-25)
Console DeviceRJ-45-to- DB-25 Terminal AdapterSwitch Console Port (DTE)
SignalDB-25 PinSignal
CTS5RTS
DSR6DTR
RxD3TxD
GND7GND
TxD2RxD
DTR20DSR
RTS4CTS
Cisco IE 4010 Switch Hardware Installation Guide
64
Cable and Connectors
Console Port Adapter Pinouts
