Cisco IE-4010-16S12P User Manual

Figure 10: Plug locations by position
For IP-30 compliance: If you use 23-inch brackets or ETSI brackets, you can insert the rubber plugs in the
same holes as shown in the figure above before installing the brackets.
Note
Attaching Brackets for 23-Inch Racks
If 23-inch brackets (RM-RGD-23IN=) are required, follow steps in the following figure for installation.
23-inch and ETSI brackets should not be used in high vibration environments, including any railway application
(EN50155).
Note
For IP-30 compliance: If you use 23-inch brackets or ETSI brackets, you can insert the rubber plugs in the
same holes as shown in Figure 11 ??? before installing the brackets.
Note
Cisco IE 4010 Switch Hardware Installation Guide
21
Switch Installation
Attaching Brackets for 23-Inch Racks
