User-supplied screws1
After the Switch is Mounted on the Wall
• Wire the switch to a power source. See Wiring the Power Source, on page 44.
• For configuration instructions about using the CLI setup program, go to Configuring the Switch with the
CLI Setup Program, on page 65.
• Connect the switch ports. See Connecting Devices to the Ethernet Ports, on page 34.
Installing and Removing SFP Modules
This section presents procedures to install and remove fiber-optic and 1000BASE-T SFP transceiver modules.
Installing SFP Modules
These sections describe how to install and remove SFP modules. SFP modules are inserted into SFP module
slots on the front of the switch. Field-replaceable SFP modules provide the uplink interfaces, send (TX) and
receive (RX).
You can use any combination of rugged SFP modules. Each SFP module must be of the same type as the SFP
module on the other end of the cable, and the cable must not exceed the stipulated cable length for reliable
communications.
For more information about SFP modules, see Cisco Transceiver Modules.
Do not insert and remove SFP modules while power is on; an electrical arc can occur. This could cause an
explosion in hazardous location installations. Be sure that power is removed or the area is nonhazardous before
proceeding. Statement 1087
Warning
Depending on the SFP module you use, the operating temperature limits may be effected. Choose an SFP
module appropriate to the installed environment.
Caution
To prevent electrostatic-discharge (ESD) damage, follow standard board and component handling procedures.
Caution
Do not install or remove the LC SFP module with fiber-optic cables attached because of potential damage to
the cables, the cable connector, or the optical interfaces in the SFP module. Disconnect all cables before
removing or installing an SFP module.
Caution
Cisco IE 4010 Switch Hardware Installation Guide
28
Switch Installation
After the Switch is Mounted on the Wall
