Information About IP Sessions over Gigabit EtherChannel
The IP sessions over Gigabit EtherChannel (IPoGEC) feature ensures consistency between systems by adding
redundancy and allows dynamic link management during local and remote system failures. LACP fast
switchover enables the standby member link to take over instantly (in milliseconds) when the active member
link goes down. As a result, the port channel remains up. The carrier-delay {delay-seconds | msec
milliseconds} command used in the configuration of the IPoGEC ensures fast switchover, with the delay in
switchover being in milliseconds rather than seconds.
Supported Features for IPoGEC
•
IPoGEC supports both simple IP sessions and mobile IP sessions.
•
IPoGEC is supported over virtual local area network (VLAN) and subinterfaces.
•
IPoGEC is supported on all Ethernet SPAs, including 10-Gigabit Ethernet ports and 1-Gigabit Ethernet
ports.
Configuring IP Sessions over Gigabit EtherChannel
SUMMARY STEPS
1.
configure terminal
2.
interface port-channel channel-number
3.
description string
4.
ip address ip-address mask [secondary [vrf vrf-name] ]
5.
load-interval seconds
6.
lacp fast-switchover
7.
lacp max-bundle max-bundle-number
8.
service-policy type control policy-map-name
9.
ip subscriber {l2-connected}
10.
initiator {dhcp | radius-proxy | static ip subscriber list listname | unclassified ip | unclassified
mac-address}
11.
initiator {dhcp | radius-proxy | static ip subscriber list listname | unclassified ip | unclassified
mac-address}
DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Router# configure terminal
Step 1
Intelligent Wireless Access Gateway Configuration Guide
26 OL-30226-03
IP Sessions Over Gigabit EtherChannel
Information About IP Sessions over Gigabit EtherChannel
