Cisco MX700 - Xconfiguration Audio Input Microphone [1..8] Videoassociation

D15335.08 Cisco TelePresence MX700 and MX800 API Reference Guide CE9.2, NOVEMBER 2017.
Copyright © 2017 Cisco Systems, Inc. All rights reserved. 49
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Audio Input Microphone [1..8] VideoAssociation
VideoInputSource
Select the video input connector to associate the audio source with.
Requires user role: ADMIN, INTEGRATOR
Default value: 1
USAGE:
xConfiguration Audio Input Microphone n VideoAssociation VideoInputSource:
VideoInputSource
where
n : Unique ID that identifies the microphone input. Range: 1..8
VideoInputSource : 1/2/3/4/5
Select the video input connector to associate the audio source with.
xConfiguration Audio Input Microphone [1..8] Level
Define the level of the Microphone input connector.
See the Audio Level table in the Physical Interface Guide for Cisco TelePresence SX80 for a
complete overview of the values represented in dB.
Requires user role: ADMIN, INTEGRATOR
Default value: 58
USAGE:
xConfiguration Audio Input Microphone n Level: Level
where
n : Unique ID that identifies the microphone input. Range: 1..8
Level : Integer (0..70)
Select a value between 0 and 70, in steps of 1 dB.
xConfiguration Audio Input Microphone [1..8] Mode
Disable or enable audio on the microphone connector.
Requires user role: ADMIN, INTEGRATOR
Default value: On
USAGE:
xConfiguration Audio Input Microphone n Mode: Mode
where
n : Unique ID that identifies the microphone input. Range: 1..8
Mode : Off/On
Off: Disable the audio input microphone connector.
On: Enable the audio input microphone connector.
xConfiguration Audio Input Microphone [1..8] Type
The microphone connectors are intended for electret type microphones. The microphone
connector can be set to line or microphone mode.
Requires user role: ADMIN, INTEGRATOR
Default value: Microphone
USAGE:
xConfiguration Audio Input Microphone n Ty p e: Type
where
n : Unique ID that identifies the microphone input. Range: 1..8
Type : Line/Microphone
Microphone: Select Microphone when you have 48 V Phantom voltage and the
pre-amplification is On.
Line: Select Line when you have a standard balanced line input. The phantom voltage
and pre-amplification is Off.
