D15335.08 Cisco TelePresence MX700 and MX800 API Reference Guide CE9.2, NOVEMBER 2017.
Copyright © 2017 Cisco Systems, Inc. All rights reserved. 50
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Audio Output Line [1..6] Channel
Define whether the Audio Line output is a mono signal or part of a multichannel signal.
Requires user role: ADMIN, INTEGRATOR
Default value: Left
USAGE:
xConfiguration Audio Output Line n Cha nnel: Channel
where
n : Unique ID that identifies the audio line output. Range: 1..6
Channel : Left/Mono/Right
Left: The Audio Line output signal is the left channel of a stereo signal.
Mono: The Audio Line output signal is a mono signal.
Right: The Audio Line output signal is the right channel of a stereo signal.
xConfiguration Audio Output Line [1..6] Delay DelayMs
To obtain lip-synchronization, you can configure each audio line output with an extra delay that
compensates for delay in other connected devices, for example TVs and external loudspeak-
ers. The delay that you set here is either fixed or relative to the delay on the HDMI output, as
defined in the Audio Output Line [n] Delay Mode setting.
Requires user role: ADMIN, INTEGRATOR
Default value: 0
USAGE:
xConfiguration Audio Output Line n Delay DelayMs: DelayMs
where
n : Unique ID that identifies the audio line output. Range: 1..6
DelayMs : Integer (0..290)
The delay in milliseconds.
xConfiguration Audio Output Line [1..6] Delay Mode
You may add extra delay to an audio line output with the Audio Output Line [n] Delay DelayMs
setting. The extra delay added is either a fixed number of milliseconds, or a number of millisec-
onds relative to the detected delay on the HDMI output (typically introduced by the connected
TV).
Requires user role: ADMIN, INTEGRATOR
Default value: Fixed
USAGE:
xConfiguration Audio Output Line n Delay Mode: Mode
where
n : Unique ID that identifies the audio line output. Range: 1..6
Mode : Fixed/RelativeToHDMI
Fixed: Any extra delay (DelayMs) added to the output, will be a fixed number of
millisecond.
RelativeToHDMI: Any extra delay (DelayMs) added to the output, will be relative to the
detected delay on the HDMI output. The actual delay is HDMI-delay + DelayMs. The
Audio Output Connectors Line [n] DelayMs status reports the actual delay.
xConfiguration Audio Output Line [1..6] Equalizer ID
Select the equalizer ID for the audio source that is connected to the output line.
Requires user role: ADMIN, INTEGRATOR
Default value: 1
USAGE:
xConfiguration Audio Output Line n Equalizer ID: ID
where
n : Unique ID that identifies the audio line output. Range: 1..6
ID : Integer (1..8)
Set the equalizer ID.
