Two power-supply cable management side frames
One cable management top hood frame
26 M4 x 12-mm, flat-head, Phillips screws
Two M4 x 14-mm, flat-head, Phillips screws
Step 1 Attach the power-supply cable management frames to the I/O-module cable management frames as follows:
a) Attach a power-supply cable management frame to the bottom of an I/O-module frame by placing the alignment pin
located at the bottom of the I/O-module frame in an alignment hole at the top of the power-supply frame, as shown
in the following figure.
A screw hole next to the alignment pin should align with a screw hole in the other frame.
Cisco Nexus 7710 Switch Site Preparation and Hardware Installation Guide
OL-30452-01.34
Installing the Chassis
Installing Cable Management Frames on a Chassis
