10-/25-Gigabit SFP28 downlink ports (4)4Port lane select button1
40-/100-Gigabit QSFP28 uplink ports (2)5Chassis LEDs (Beacon [BCN], Status [STS], and
Environment [ENV]
2
Screw holes (6) for attaching rack mounting
brackets
6100-/1000-Megabit 1GBASE-T downlink ports
(48)
3
To determine which transceivers, adapters, and cables this switch supports, see the Cisco Transceiver Modules
Compatibility Information document.
The following figure shows the hardware features seen from the power supply side of the chassis.
Cisco Nexus 9348GC-FXP NX-OS Mode Hardware Installation Guide
5
Overview
Overview
