Administration: Discovery
Configuring LLDP
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 94
8
STEP 3 Click LLDP Port Status Table to display the details of LLDP port status in a table.
Viewing LLDP Neighbors Information
The LLDP Neighbor page displays information that was received using the LLDP
protocol from neighboring devices. After timeout (based on the value received
from the neighbor Time To Live TLV during which no LLDP PDU was received from
a neighbor), the information is deleted.
To view the LLDP neighbors information:
STEP 1 Click Administration > Discovery LLDP > LLDP Neighbor.
STEP 2 Select a local port, and click Go.
The following fields are displayed:
• Local Port—Number of the local port to which the neighbor is connected.
• Chassis ID Subtype—Type of chassis ID (for example, MAC address).
• Chassis ID—Identifier of the 802 LAN neighboring device's chassis.
• Port ID Subtype—Type of the port identifier that is shown.
• Port ID—Identifier of port.
• System Name—Published name of the switch.
• Time to Live—Time interval in seconds after which the information for this
neighbor is deleted.
STEP 3 Click Detail to display the details of LLDP port status in a table.
STEP 4 Click Refresh to refresh the data in the LLDP Neighbor table.
