Cisco SF220-24 Administration Guide

SNMP
Configuring SNMP Notification Recipients
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 285
19
Configuring SNMPv3 Notification Recipients
To define a recipient in SNMPv3:
STEP 1 Click SNMP > Notification Recipients SNMPv3.
STEP 2 To add an SNMPv3 notification recipient, click Add.
STEP 3 Enter the following information:
• Server Definition—Select whether to define the notification recipient by IP
address or name.
• IP Version—Select either Version 4 or Version 6 if the notification recipient
is identified by IP address.
• Recipient IP Address/Name—Enter the IP address or hostname of the
notification recipient that the traps are sent.
• UDP Port—Enter the UDP port used for notifications on the recipient device.
• Notification Type—Select whether to send Traps or Informs. If both are
required, two recipients must be created.
• Timeout—Enter the number of seconds that the switch waits before re-
sending informs. The default is 15 seconds.
• Retries—Enter the number of times that the switch resends an inform
request. The default is 3.
• User Name—Select the user to whom SNMP notifications are sent. In order
to receive notifications, this user must be defined on the Users page, and its
Engine ID must be remote.
• Security Level—Select how much authentication is applied to the packet.
The options are:
-
No Authentication —Indicates that the packet is neither authenticated nor
encrypted.
-
Authentication —Indicates that the packet is authenticated but not
encrypted.
-
Privacy —Indicates that the packet is both authenticated and encrypted.
