Status and Statistics
Viewing Fan Status and Temperature
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 25
2
Viewing Fan Status and Temperature
The Fan and Thermal Status page displays the fan and temperature status of the
switches with PoE capabilities.
The following table lists the number of fan channels and temperature channels
applicable on different PoE switch models:
To view the fan and temperature status, click Status and Statistics > Fan and
Thermal Status.
The following fields are displayed:
• FAN
x
Status—Displays the operation status of the switch fans.
-
Operational Status
—Displays OK if the fan operates normally, or
displays Fault if the fan does not operate normally.
-
Speed Value
—Displays the fan speed in revolutions per minute (RPM).
• Thermal
x
Status—Displays the status of the switch thermals.
-
Operational Status
—Displays OK when the thermal operates normally,
or displays Fault when the thermal does not operate normally.
-
Temperature Value
—Displays the current temperature in Celsius.
Model Number of Fan
Channels
Number of Temperature
Channels
SF220-24P 2 2
SF220-48P 4 2
SG220-26P 2 2
SG220-28MP 3 2
SG220-50P 4 2
