Cisco SF220-24P Administration Guide

Status and Statistics
Managing RMON
Cisco 220 Series Smart Switches Administration Guide Release 1.1.0.x 33
2
Configuring RMON Events
Use the Events page to configure events that are actions performed when an
alarm is generated (alarms are defined on the Alarms page). An event can be any
combination of logs and traps. If the action includes logging of the events, they are
displayed on the Event Log Table page.
To configure RMON events:
STEP 1 Click Status and Statistics > RMON > Events.
STEP 2 Click Add to add an RMON event.
STEP 3 Enter the following information:
• Event Entry—Displays the number for the event entry.
• Community— Enter the SNMP community string to be included when traps
are sent.
• Description—Enter a name for the event. This name is used to attach an
alarm to an event.
• Notification Type—Select the type of action that results from this event.
The available options are:
-
None —No action occurs when the alarm goes off.
-
Log (Event Log Table) —Add a log entry to the Event Log Table when the
alarm goes off.
-
Trap (S NMP Manager) —Send a trap when alarm goes off.
-
Log and Trap —Add a log entry to the Event Log Table and send a trap to
the remote log server when the alarm goes off.
• Owner—Enter the device or user that defined the event.
STEP 4 Click Apply. The RMON event is added, and the Running Configuration is updated.
STEP 5 Click Event Log Table to display the log of alarms that have occurred and that
have been logged.
