Administration: Discovery

Discover - LLDP

136 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4

NOTE When this box is checked, you may not manually configure a voice network

policy.

STEP 3 Click Apply to add this setting to the Running Configuration file.

STEP 4 To define a new policy, click Add.

STEP 5 Enter the values:

• Network Policy Number—Select the number of the policy to be created.

• Application—Select the type of application (type of traffic) for which the network

policy is being defined.

• VLAN ID—Enter the VLAN ID to which the traffic must be sent.

• VLAN Type—Select whether the traffic is Tagged or Untagged.

• User Priority—Select the traffic priority applied to traffic defined by this network

policy. This is the CoS value.

• DSCP Value—Select the DSCP value to associate with application data sent by

neighbors. This value informs them how they must mark the application traffic they

send to the device.

STEP 6 Click Apply. The network policy is defined.

NOTE You must manually configure the interfaces to include the desired manually-

defined network policies for the outgoing LLDP packets using the LLDP MED Port

Settings.

LLDP MED Port Settings

The LLDP MED Port Settings page enables the selection of the LLDP-MED TLVs and/or the

network policies to be included in the outgoing LLDP advertisement for the desired interfaces.

Network policies are configured using the LLDP MED Network Policy page.

NOTE If LLDP-MED Network Policy for Voice Application (LLDP MED Network Policy Page) is

Auto and Auto Voice VLAN is in operation, then the device automatically generates an LLDP-

MED Network Policy for Voice Application for all the ports that are LLDP-MED enabled and

are members of the voice VLAN.
