Cisco SF350-24P Administration Guide

Security: IPv6 First Hop Security
IPv6 First Hop Security Overview
441 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
26
IPv6 First Hop Security Overview
IPv6 FHS is a suite of features designed to secure link operations in an IPv6-enabled network.
It is based on the Neighbor Discovery Protocol and DHCPv6 messages.
In this feature, a Layer 2 switch (as shown in Figure 1) filters Neighbor Discovery Protocol
messages, DHCPv6 messages and user data messages according to a number of different rules.
Figure 1 IPv6 First Hop Security Configuration
A separate and independent instance of IPv6 First Hop Security runs on each VLAN on which
the feature is enabled.
Abbreviations
IPv6 Host
(End Node)
Monitor
First Hop Switch IPv6 Router
370572
Name Description
CPA message Certification Path Advertisement message
CPS message Certification Path Solicitation message
DAD-NS message Duplicate Address Detection Neighbor Solicitation
message
FCFS-SAVI First Come First Served - Source Address Validation
Improvement

Cisco SF350-24P Specifications

General

Model	SF350-24P
Category	Switch
PoE Budget	195W
Layer	Layer 3
Power Supply	Internal
Uplink Ports	2 x combo Gigabit SFP + 2 x Gigabit
MAC Address Table Size	16K entries
Jumbo Frame Support	9216 bytes
Management	Web, CLI, SNMP
Features	QoS, VLAN, IPv6, ACLs
Dimensions	440 mm x 257 mm x 44 mm
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
Weight	3.48 kg
