Cisco SF350-24P Administration Guide

Security: SSH Server
SSH Server Authentication
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 383
20
• Automatic Login—This field can be enabled if the SSH User Authentication by
Public Key feature was selected.
STEP 3 Click Apply. The settings are saved to the Running Configuration file.
The following fields are displayed for the configured users:
• SSH User Name—User name of user.
• Key Type—Whether this is an RSA or DSA key.
• Fingerprint—Fingerprint generated from the public keys.
STEP 4 Click Add to add a new user and enter the fields:
• SSH User Name—Enter a user name.
• Key Type—Select either RSA or DSA.
• Public Key—Copy the public key generated by an external SSH client application (like
PuTTY) into this text box.
STEP 5 Click Apply to save the new user.
The following fields are displayed for all active users:
• IP Address—IP address of the active user.
• SSH User Name—User name of the active user.
• SSH Version—Version of SSH used by the active user.
• Cipher—Cipher of the active user.
• Authentication Code—Authentication code of the active user.
SSH Server Authentication
A remote SSH client can perform SSH Server Authentication to ensure it is establishing a SSH
session to the expected SSH driver. To perform SSH Server Authentication, the remote SSH
client must have a copy of the SSH server public key (or fingerprint) of the target SSH server

Cisco SF350-24P Specifications

General

Model	SF350-24P
Category	Switch
PoE Budget	195W
Layer	Layer 3
Power Supply	Internal
Uplink Ports	2 x combo Gigabit SFP + 2 x Gigabit
MAC Address Table Size	16K entries
Jumbo Frame Support	9216 bytes
Management	Web, CLI, SNMP
Features	QoS, VLAN, IPv6, ACLs
Dimensions	440 mm x 257 mm x 44 mm
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
Weight	3.48 kg
