Access Control
IPv4-based ACL Creation
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 401
22
NOTE Given a mask of 0000 0000 0000 0000 0000 0000 1111 1111 (which means that
you match on the bits where there is 0 and don't match on the bits where there are 1's).
You need to translate the 1's to a decimal integer and you write 0 for each four zeros. In
this example since 1111 1111 = 255, the mask would be written: as 0.0.0.255.
Source MAC Address—Select Any if all source address are acceptable or User defined
to enter a source address or range of source addresses.
Source MAC Address Value—Enter the MAC address to which the source MAC
address is to be matched and its mask (if relevant).
Source MAC Wildcard Mask—Enter the mask to define a range of MAC addresses.
VLAN ID—Enter the VLAN ID section of the VLAN tag to match.
802.1p—Select Include to use 802.1p.
802.1p Value—Enter the 802.1p value to be added to the VPT tag.
802.1p Mask—Enter the wildcard mask to be applied to the VPT tag.
Ethertype—Enter the frame Ethertype to be matched.
STEP 5 Click Apply. The MAC-based ACE is saved to the Running Configuration file.
IPv4-based ACL Creation
IPv4-based ACLs are used to check IPv4 packets, while other types of frames, such as ARPs,
are not checked.
The following fields can be matched:
IP protocol (by name for well-known protocols, or directly by value)
Source/destination ports for TCP/UDP traffic
Flag values for TCP frames
ICMP and IGMP type and code
Source/destination IP addresses (including wildcards)
DSCP/IP-precedence value
NOTE ACLs are also used as the building elements of flow definitions for per-flow QoS handling.
