Security: 802.1X Authentication
Authenticated Hosts
370 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
18
Single Host Violation Settings (only displayed if host authentication is Single Host):
Action on Violation—Select the action to be applied to packets arriving in Single
Session/Single Host mode, from a host whose MAC address is not the supplicant MAC
address. The options are:
- Protect (Discard)—Discards the packets.
- Restrict (Forward)—Forwards the packets.
- Shutdown—Discards the packets and shuts down the port. The ports remains shut
down until reactivated, or until the device is rebooted.
Traps—Select to enable traps.
Trap Frequency—Defines how often traps are sent to the host. This field can be
defined only if multiple hosts are disabled.
STEP 4 Click Apply. The settings are written to the Running Configuration file.
Authenticated Hosts
To view details about authenticated users, click Security > 802.1X Authentication >
Authenticated Hosts.
This page displays the following fields:
User Name—Supplicant names that authenticated on each port.
Port—Number of the port.
Session Time (DD:HH:MM:SS)—Amount of time that the supplicant was
authenticated and authorized access at the port.
Authentication Method—Method by which the last session was authenticated.
Authentication Server—RADIUS server.
MAC Address—Displays the supplicant MAC address.
VLAN ID—Port’s VLAN.
