IP Configuration: SLA
Using SLA
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 358
20
Using SLA
ICMP-Echo Operations
IP SLA ICMP-Echo operations can be configured in this page. These operations will be
executed according to the frequency entered.
STEP 1 Click IP Configuration > IPv4 Management and Interfaces > SLA > ICMP-Echo
Operations.
The ICMP-Echo operations are displayed (some fields described in the Add page):
• State—Displays either Pending or Scheduled, as described in the Overview above.
• Return Code—Displays either OK or Error, as described in the Overview above.
STEP 2 To add a new operation, click Add.
STEP 3 Enter the following fields:
• Operation Number—Enter an unused number.
• Operation State—Select one of the following options:
- Pending—Operation is not activated.
- Scheduled—Operation is activated.
ICMP-Echo Parameters
• Operation Target—Select how the operation target is defined:
- By IP—Enter the operation target’s IP address.
- By host name—Enter the operation target’s host name.
NOTE If the IP SLA operation is for the Static Routes feature, the operation target is the
IP address of the host in the remote network defined by the static route.
• Source Definition—If this field is not defined, the operation selects the source IP
address nearest to the destination. To define this field, select from one of the following
options:
- Auto—The source interface is based on Forwarding Table information.
- By address— Specify a different source IP address.
