Quick Getting Started
98DX4203, 98DX4204, 98DX4210, 98DX4211, and 98DX4212Switch Features
30 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
1
The following are per port LEDs:
LINK/ACT—(Green) Located on the left of each port. The LED lights steady when a
link between the corresponding port and another device is detected, and flashes when
the port is passing traffic.
XG—(Green) Located on the right of a 10G port. The LED lights steady when another
device is connected to the port, is powered on, and a 10 Gbps link is established
between the devices. When the LED is off, the connection speed is under 10 Gbps or
nothing is cabled to the port.
Gigabit—(Green) Located on the right of the OOB port. The LED lights steady when
another device is connected to the port, is powered on, and a 1000 Mbps link is
established between the devices. When the LED is off, the connection speed is under
1000 Mbps or nothing is cabled to the port.
SFP+ (if present)—(Green) Located on the right of a 10G port. The LED lights steady
when a connection is made through the shared port, and flashes when the port is
passing traffic.
PoE (if present)—(Amber) Located on the right of the port. The LED lights steady
when power is being supplied to a device attached to the corresponding port.
Reset Button
The switch can be reset by inserting a pin or paper clip into the Reset button opening on the
front panel of the switch. To use the Reset button to reboot or reset the switch, do the
following:
To reboot the switch, press and hold the Reset button for less than ten seconds.
To restore the switch to its factory default settings:
- Disconnect the switch from the network or disable all DHCP servers on your
network.
- With the power on, press and hold the Reset button for more than ten seconds.
Back Panel
The following buttons are found on the back panels:
Power—Connects the switch to AC power.
Console—Connects a serial cable to a computer serial port so that it can be configured
by using a terminal emulation program.
