Cisco SF350-24P Administration Guide

IP Configuration: RIPv2
Configuring RIP
341 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
18
To enable/disable RIP on the device.
STEP 1 Click IP Configuration > IPv4 Management and Interfaces> RIPv2 > RIPv2 Properties.
STEP 2 Select the following options as required:
• RIP—The following options are available:
- Enable—Enable RIP.
- Disable—Disable RIP. Disabling RIP deletes the RIP configuration on the system.
- Shutdown—Set the RIP global state to shutdown.
• RIP Advertisement—Select to enable sending routing updates on all RIP IP interfaces.
• Default Route Advertisement—Select to enable sending the default route to the RIP
domain. This route will serve as the default router.
• Default Metric—Enter the value of the default metric (refer to Redistribution Feature).
STEP 3 Redistribute Static Route—Select to enable this feature (described in Redistribution Feature.
STEP 4 If Redistribute Static Route is enabled, select an option for the Redistribute Static Metric
field. The following options are available:
• Default Metric—Causes RIP to use the default metric value for the propagated static
route configuration (refer to Redistribution Feature).
• Transparent—Causes RIP to use the routing table metric as the RIP metric for the
propagated static route configuration. This results in the following behavior:
- If the metric value of a static route is equal to or less than 15, this value is used in
the RIP protocol when advertising this static route.
- If the metric value of a static route is greater than 15, the static route is not advertised
to other routers using RIP.
• User Defined Metric—Enter the value of the metric.
STEP 5 Redistribute Connected Route—Select to enable this feature (described in Redistributing
Static Route Configuration.
STEP 6 If Redistribute Connected Route is enabled, select an option for the Redistribute
Connected Metric field. The following options are available:
• Default Metric—Causes RIP to use the default metric value for the propagated static
route configuration (refer to Redistribution Feature).

Cisco SF350-24P Specifications

General

Model	SF350-24P
Category	Switch
PoE Budget	195W
Layer	Layer 3
Power Supply	Internal
Uplink Ports	2 x combo Gigabit SFP + 2 x Gigabit
MAC Address Table Size	16K entries
Jumbo Frame Support	9216 bytes
Management	Web, CLI, SNMP
Features	QoS, VLAN, IPv6, ACLs
Dimensions	440 mm x 257 mm x 44 mm
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
Weight	3.48 kg
