Security
Denial of Service Prevention
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 375
17
To configure fragmented IP blocking:
STEP 1 Click Security > Denial of Service Prevention > IP Fragments Filtering.
STEP 2 Click Add.
STEP 3 Enter the parameters.
Interface—Select the interface on which the IP fragmentation is being defined.
IP Address—Enter an IP network from which the fragmented IP packets is filtered or
select All Addresses to block IP fragmented packets from all addresses. If you enter the
IP address, enter either the mask or prefix length.
Network Mask—Select the format for the subnet mask for the source IP address, and
enter a value in one of the field:
- Mask—Select the subnet to which the source IP address belongs and enter the
subnet mask in dotted decimal format.
- Prefix Length—Select the Prefix Length and enter the number of bits that comprise
the source IP address prefix.
STEP 4 Click Apply. The IP fragmentation is defined, and the Running Configuration file is updated.

Table of Contents

Other manuals for Cisco SF350-24P

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco SF350-24P and is the answer not in the manual?

Cisco SF350-24P Specifications

General IconGeneral
ModelSF350-24P
CategorySwitch
PoE Budget195W
LayerLayer 3
Power SupplyInternal
Uplink Ports2 x combo Gigabit SFP + 2 x Gigabit
MAC Address Table Size16K entries
Jumbo Frame Support9216 bytes
ManagementWeb, CLI, SNMP
FeaturesQoS, VLAN, IPv6, ACLs
Dimensions440 mm x 257 mm x 44 mm
Operating Temperature0°C to 45°C
Operating Humidity10% to 90% non-condensing
Weight3.48 kg
